Product Description
RC4WD has teamed up with Baja Designs to offer this awesome new licensed product to the scale community. Perfect for any project these little units work great at lighting the way. Made to fit anywhere.Â
Specifications:
- Plastic Molded Housing
- Adjustable Bracket for Rotating Light
- 4 Individual LED Bulbs
- Super Bright Lighting
- Standard Receiver Plug
- Connects to Extra Channel on Receiver
- Connects Directly to Battery
- Capable of 11.1v
- 2mm Mounting Holes
- Overall Length: 0.57in /Â 14.5mm
- Light Bar Width: 0.52in / 13.4mm
- Overall Height: 0.57in / 14.7mm
- Light Bar Height: 0.55in / 14.2mm
- Weight: 0.1oz / 3g
What's Included:
- 2x RC4WD 1/10 Baja Designs Squadron Pro LED Lights
- 1x Baja Designs Decal Sheet
Replacement Hardware:
- M2 X 6mm Steel Socket Head Cap Screws (Black)Â
- M1.4 x 3mm Phillips Button Head (Silver)
- M1.2 x 3mm Phillips Flat Head (Silver)
Notes:
- This unit has to be connected directly to 2 or 3 cell lipo to operate properly with 7.4 volts and 11.1 volts.
- Mounting hardware can be found here.Â
- While the lightbar comes with a standard receiver plug, this is only for ease of use. The receiver will not allow enough power for the lightbar and it will be dim. If you want the light to be bright, you will need to power it directly from your battery, or use a BEC to get more power to your receive
